FSB-007 EL 120V 5/16 https://www.bdiexpress.com/medias/INDBALBRAKEX-EL-FSB-FLG-300x300.jpg?context=bWFzdGVyfHJvb3R8MTc5MDJ8aW1hZ2UvanBlZ3xhR1UxTDJoalpDOHhNRFkyT1RrM01qVXlNRGs1TUM5SlRrUkNRVXhDVWtGTFJWaGZSVXhmUmxOQ1gwWk1SMTh6TURCNE16QXdMbXB3Wnd8MDFiZDQwY2FkMjZhMDExNDA1NTE5YzI3MGQ2YTYwYzA4ZWMwNjZmOGI4MWNhNjY2YWZlNTRmNTE1MmVmNmU1NQ
241319 Electric Clutches and Brakes

BALDOR-RELIANCE BALDOR-RELIANCE

FSB-007 EL 120V 5/16

Description

FSB-007 EL BRAKE 120V 5/16 ; MTO

Electrical Braking System; Straight | Finished; 5/16" Bore; Hollow Bore Input; Hollow Bore Output; Flange Mounted | Shaft Mount; 120VAC Voltage; Bidirectional Rotation; Static Torque 7Lb-in

Part #

FSB-007 EL 120V 5/16

BDI #
241319

Details

2099-12-31 http://schema.org/NewCondition https://schema.org/LimitedAvailability Your Price Request A Price BDIExpress
QTY

Inventory

Total: Available to order

Category
Electric Clutches and Brakes
Brand
BALDOR-RELIANCE
Manufacturer Name
ABB GROUP
Minimum Buy Quantity
N/A
UNSPSC
26111500
Weight / Kilogram
0.427
EAN
0782475509416
Product Group - BDI
C02104
Product Name
Brake
Activation
Electrical
Bore Profile
Straight | Finished
Input Type
Hollow Bore
Output Type
Hollow Bore
Mounting Method
Flange Mounted | Shaft
Voltage Rating
120VAC
Direction of Rotation
Bidirectional
Number of Stop Collars
0
Torque
Static Torque 7Lb-in
Product Type
Friction Disc
Motion Type
Decelerate | Holding
Actuation/Return
Coil
Product Series
FSB
Housing Style
Cylindrical
Shaft-Thru/End
Thru
Power Off Status
Engagement
Frequency Hz
60/50
Phase
Single Phase
Number of Friction Discs
1
Lead Wire Position
External
Inch - Metric
Inch
Other Features
Fail Safe | Non-Asbestos | Non-Lead Friction Material
Category - BDI
Clutches and Brakes
Harmonized Tariff Code
8505.20.00.00
Noun
Braking System
Keyword String
Electrical
Manufacturer URL
https://www.baldor.com
Weight / LBS
0
Long Description
Electrical Braking System; Straight | Finished; 5/16" Bore; Hollow Bore Input; Hollow Bore Output; Flange Mounted | Shaft Mount; 120VAC Voltage; Bidirectional Rotation; Static Torque 7Lb-in
Bore
0.313 Inch | 7.95 Millimeter
