53-SY5140-TT100-02 https://www.bdiexpress.com/medias/INDSMCVALVEX-SY5140-TT-02-300x300.jpg?context=bWFzdGVyfHJvb3R8MTUyNzl8aW1hZ2UvanBlZ3xhRGhtTDJoak1DOHhNRGswTURjM056WTVNekl4TkM5SlRrUlRUVU5XUVV4V1JWaGZVMWsxTVRRd1gxUlVYekF5WHpNd01IZ3pNREF1YW5Cbnw1NmU5ODMzNDA4ZTlkOGUxMmQwZjQ2YTY1Zjc5Y2NkOWY1ODI1NDBiOWM3N2U1YTNiZjA1MmNhMWUyNWI2ZDgz
27610637 Hydraulic and Pneumatic Valves

SMC SMC

53-SY5140-TT100-02

Description

53-SY5140-TT100-02, INTRISICALLY SAFE SY VALVE (SMARTCATALOG)

Solenoid Valve; 1/4" RC; 5 Port | 4 Way; 2 Position; 12 VDC; Pneumatic; Solenoid - Air Pilot | Air Pilot Return; 102 PSI; 14 To 122 Deg F; Rubber Seal; Aluminum

Part #

53-SY5140-TT100-02

BDI #
27610637

Details

2099-12-31 http://schema.org/NewCondition https://schema.org/LimitedAvailability Your Price Request A Price BDIExpress
QTY

Inventory

Total: Available to order

Category
Hydraulic and Pneumatic Valves
Brand
SMC
Manufacturer Name
SMC
Minimum Buy Quantity
1
Weight / gram
4701
Product Group - BDI
F02234
Valve Type
Solenoid
Port Type
1/4" RC
Number of Ports/Way
5 Port | 4 Way
Number of Positions
2 Position
Actuation
Solenoid - Air Pilot | Air Pilot Return
Voltage
12 VDC
Media
Pneumatic
Maximum Pressure
102 PSI
Operating Pressure Range
22 To 102 PSI
Operating Temperature Range
14 To 122 Deg F
Seal Type
Rubber
Body Material
Aluminum
Inch - Metric
Inch
Other Features
Air Fluid | Base Mounted | Plug Connector with Cover Type | UL/CSA Compliant
Category - BDI
Hydraulic and Pneumatic Valve
Harmonized Tariff Code
8481.20.00.60
Noun
Valve
Keyword String
Solenoid
Manufacturer URL
https://www.smcworld.com
Weight / LBS
10.36392
Long Description
Solenoid Valve; 1/4" RC; 5 Port | 4 Way; 2 Position; 12 VDC; Pneumatic; Solenoid - Air Pilot | Air Pilot Return; 102 PSI; 14 To 122 Deg F; Rubber Seal; Aluminum
Overall Height
2.461 Inch | 62.5 Millimeter
Overall Length
5.15 Inch | 130.8 Millimeter
Overall Width
1.378 Inch | 35 Millimeter
