TC880 PRINT P-41139 https://www.bdiexpress.com/medias/INDM-GGEARXX-SPUR-RSB-HB-CI-300x300.jpg?context=bWFzdGVyfHJvb3R8Mzk3NTZ8aW1hZ2UvanBlZ3xhRFptTDJneE55OHhNRE0wTXpnMU56SXlOVGMxT0M5SlRrUk5MVWRIUlVGU1dGaGZVMUJWVWw5U1UwSmZTRUpmUTBsZk16QXdlRE13TUM1cWNHY3wwNjQwOTQ3NzkzMTFkZWJmMTUxZTlmNjg0MzdmNWJmZjllNTRkOWI4YTIxYzcwZjAzY2VkOGZlNmQ4NTY5YjQx
21516625 Spur and Helical Gears

MARTIN SPROCKET & GR MARTIN SPROCKET & GR

TC880 PRINT P-41139

Description

TC880 PRINT P-41139 GEAR ; STEEL AND CAST STOCK SPUR GEAR 1-1/2IN

Spur Gear; 10" Pitch Diameter; 8 DP; 1-1/2" Face Width; Rough Bore; 80 Teeth; 20 Degree Pressure Angle; Yes Minimum Plain Bore; 2-1/16" Max Bore; 3-1/4" Hub Diameter; Cast Iron; No Hardened Teeth

Part #

TC880 PRINT P-41139

BDI #
21516625

Details

2099-12-31 http://schema.org/NewCondition https://schema.org/LimitedAvailability Your Price Request A Price BDIExpress
QTY

Inventory

Total: Available to order

Category
Spur and Helical Gears
Brand
MARTIN SPROCKET & GR
Manufacturer Name
MARTIN SPROCKET & GEAR
Minimum Buy Quantity
N/A
UNSPSC
31171707
Weight / Kilogram
7.71
Product Group - BDI
M02182
Pitch
8 DP
Mounting Method
Rough Bore
Number of Teeth
80
Pressure Angle
20
Direction
Not Applicable
Bushing Size if bushed
No Bushing
Minimum Plain Bore
Yes
Max Bore
2.063
Gear Style
Spur Gear
Material
Cast Iron
Hardened Teeth
No
Inch - Metric
Inch
Category - BDI
Spur and Helical Gears
Harmonized Tariff Code
8483.40.90.00
Noun
Gear
Keyword String
Spur
Manufacturer URL
http://www.martinsprocket.com
Long Description
Spur Gear; 10" Pitch Diameter; 8 DP; 1-1/2" Face Width; Rough Bore; 80 Teeth; 20 Degree Pressure Angle; Yes Minimum Plain Bore; 2-1/16" Max Bore; 3-1/4" Hub Diameter; Cast Iron; No Hardened Teeth
Hub Diameter
3.25 Inch | 82.55 Millimeter
Pitch Diameter
10 Inch | 254 Millimeter
Face Width
1.5 Inch | 38.1 Millimeter
Bore
0 Inch | 0 Millimeter
