VNA211A-15A-1DZ https://www.bdiexpress.com/medias/INDSMCVALVEX-VNA2-S-D-300x300.jpg?context=bWFzdGVyfHJvb3R8NTA5NXxpbWFnZS9qcGVnfGFHVm1MMmhsWmk4eE1EYzJPVFEyTkRNMk1EazVNQzlKVGtSVFRVTldRVXhXUlZoZlZrNUJNbDlUWDBSZk16QXdlRE13TUM1cWNHY3w4ZjVhY2ZiYzMyOThkOGM2MjE1ZDhhM2YzNTI4Y2MzNzNmZmNhZjEwMzE2MDgzY2E2ZGYzMDdiNDMxOGE4N2E0
25811649 Hydraulic and Pneumatic Valves

SMC SMC

VNA211A-15A-1DZ

Description

VNA211A-15A-1DZ PROCESS VALVE (SMARTCATALOG)

Valve; 1/2" RC Port; 2 Port - 2 Way; 2 Position; Hydraulic - Pneumatic; 100/50-60 VAC; Solenoid - Air Pilot/Spring Return; 145 PSI; 23 To 140 Deg F; Buna-N Seal; Aluminum

Part #

VNA211A-15A-1DZ

BDI #
25811649

Details

2099-12-31 http://schema.org/NewCondition https://schema.org/LimitedAvailability Your Price Request A Price BDIExpress
QTY

Inventory

Total: Available to order

Category
Hydraulic and Pneumatic Valves
Brand
SMC
Manufacturer Name
SMC
Minimum Buy Quantity
1
Weight / Kilogram
0.4
Product Group - BDI
F02234
Valve Type
Solenoid
Port Type
1/2" RC
Number of Ports/Way
2 Port | 2 Way
Number of Positions
2 Position
Actuation
Solenoid - Air Pilot | Spring Return
Voltage
100/50-60 VAC
Media
Hydraulic | Pneumatic
Maximum Pressure
145 PSI
Operating Pressure Range
0 To 145 PSI
Operating Temperature Range
23 To 140 Deg F
Seal Type
Buna-N
Body Material
Aluminum
Inch - Metric
Inch
Other Features
1.9 Cv Factor | 10MM Orifice Size | Normally Closed | DIN Terminal with Connector | With Light/Surge Voltage Suppressor | Non Locking Push Type Manual Override | In/Out Position
Category - BDI
Hydraulic and Pneumatic Valve
Harmonized Tariff Code
8481.20.00.60
Noun
Valve
Keyword String
Solenoid
Manufacturer URL
https://www.smcworld.com
Weight / LBS
1.00471
Long Description
Valve; 1/2" RC Port; 2 Port - 2 Way; 2 Position; Hydraulic - Pneumatic; 100/50-60 VAC; Solenoid - Air Pilot/Spring Return; 145 PSI; 23 To 140 Deg F; Buna-N Seal; Aluminum
Overall Height
5.689 Inch | 144.5 Millimeter
Overall Width
1.654 Inch | 42 Millimeter
Overall Length
3.996 Inch | 101.5 Millimeter
