VQC2200N-51 https://www.bdiexpress.com/medias/INDSMCVALVEX-VQC2200-5-300x300.jpg?context=bWFzdGVyfHJvb3R8MjA0MjB8aW1hZ2UvanBlZ3xhRGd6TDJnMlpDOHhNRFl3TmpNNU5qVTNNVFkzT0M5SlRrUlRUVU5XUVV4V1JWaGZWbEZETWpJd01GODFYek13TUhnek1EQXVhbkJufDI1NDNiZjcyZTRmMmVkZjg3MTk3M2E2NTgzZmY2NjFmZmYzZGNkM2JlODM1MmJmM2ZiMjBiNDhjMzIxNTc3OTM
17877638 Hydraulic and Pneumatic Valves

SMC SMC

VQC2200N-51

Description

VQC2200N-51 SOLENOID VALVE ; 5 PORT 4 WAY/2 POSITION 24VDC

Solenoid Valve; 5 Port | 4 Way; 2 Position; 24 VDC; Pneumatic; Solenoid - Air Pilot - Detent | Solenoid - Air Pilot Return; 102 PSI; 14 To 122 Deg F; Metal Seal; Zinc

Part #

VQC2200N-51

BDI #
17877638

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Details

137.61 USD 2099-12-31 http://schema.org/NewCondition http://schema.org/InStock Your Price $ 137.61 / each BDIExpress
QTY

Inventory

Total: 3

Category
Hydraulic and Pneumatic Valves
Brand
SMC
Manufacturer Name
SMC
Minimum Buy Quantity
N/A
UNSPSC
40141605
Weight / Kilogram
0.118
Product Group - BDI
F02352
Valve Type
Solenoid
Port Type
Not Available
Number of Ports/Way
5 Port | 4 Way
Number of Positions
2 Position
Actuation
Solenoid - Air Pilot - Detent | Solenoid - Air Pilot Return
Voltage
24 VDC
Media
Pneumatic
Maximum Pressure
102 PSI
Operating Pressure Range
15 To 102 PSI
Operating Temperature Range
14 To 122 Deg F
Seal Type
Metal
Body Material
Zinc
Inch - Metric
Inch
Other Features
0.46 - 0.6 Cv Factor | Negative Common | With Light and Surge Voltage Suppressor | Non Locking Push Type
Category - BDI
Hydraulic and Pneumatic Valve
Harmonized Tariff Code
8481.20.00.60
Noun
Valve
Keyword String
Solenoid
Manufacturer URL
https://www.smcpneumatics.com
Weight / LBS
0.24251
Long Description
Solenoid Valve; 5 Port | 4 Way; 2 Position; 24 VDC; Pneumatic; Solenoid - Air Pilot - Detent | Solenoid - Air Pilot Return; 102 PSI; 14 To 122 Deg F; Metal Seal; Zinc
Overall Width
0.61 Inch | 15.5 Millimeter
Overall Height
2.165 Inch | 55 Millimeter
Overall Length
4.606 Inch | 117 Millimeter
